| X | 30" | 762 mm |
| Y | 22" | 558.8 mm |
| Z | 20" | 508 mm |
| # Axis | 5 | 5 |
| Power | 30 hp | 22.4 kW |
| RPM | 8,100 RPM | 8,100 RPM |
| # ATC | 41 | 41 |
| Taper | CT 40 | CT 40 |
| Table-W | 19.7" | 500.38 mm |
| Table-L | 24.8" | 629.92 mm |
| Control | CNC (Next Gen) | CNC (Next Gen) |
| Dimensions | 162″ X 113″ X 120″ | 162″ X 113″ X 120″ |
| Weight | 19100 | 19100 |
Spindles
8100-rpm Spindle
Tool Changers
30+1 Side-Mount Tool Changer
Probing
Wireless Intuitive Probing System
Chip & Coolant Management
Auxiliary Coolant Filter
Chip Tray Filter Kit
Through-Spindle Coolant, 300 psi (21 bar)
Belt-Type Chip Conveyor UMC
Through-Tool Air Blast
55-Gallon Coolant Tank
The Haas Control
Standard Low-Volt Transformer
CNC Control Cabinet Cooler
Standard Program Memory, 1 GB
Dynamic Work Offsets and Tool Center Point Control
Early Power-Failure Detection Module
Ethernet Interface
HaasConnect: Remote monitoring
HaasDrop
Second Home Position
High-Speed Machining
Media Display M-Code; M130
Rigid Tapping
Safe Run
WiFi Connection for the Haas Control
Product Options
Rotary Scales
Top Cover for UMC Series
Legacy Options
CT-Style Tool Changer Grippers
Remote Jog Handle, Touchscreen
